Planter IMPACT NS

Planter Impact NS

1. Double-sided fertilisation with disc units.
2. Seeding units for precise seed distribution.

Impact is designed for precise seeding of wide-row crops (maize, sunflower, and rapeseed) with the option of additional fertilization using granulated fertilizers. Impact has a massive frame. Ensuring precise placement of the fertilizer and the seeds in the required depth, also in heavier soil conditions.

The system of tandem-configured disc fertilization units not only provides precise double-sided placement of fertilizer in the root zone, but also strip-till pre-processing allowing for subsequent precise placement of seeds into the prepared seedbed.

The design of the Impact seed drill allows reaching high working speed according to the soil conditions: from 10 to 15km/h.

Impact is designed for precise seeding of wide-row crops (maize, sunflower, and rapeseed) with the option of additional fertilization using granulated fertilizers. Impact has a massive frame. Ensuring precise placement of the fertilizer and the seeds in the required depth, also in heavier soil conditions.

The system of tandem-configured disc fertilization units not only provides precise double-sided placement of fertilizer in the root zone, but also strip-till pre-processing allowing for subsequent precise placement of seeds into the prepared seedbed.

The design of the Impact seed drill allows reaching high working speed according to the soil conditions: from 10 to 15km/h.

High performance and quality of work

• High working speed of up to 15km/h, high seeding amount reliability.
• Highly advanced system of electronic control of each seed.
• Electronic control of all functions of the machine during work – ISO bus system.
• Double-sided fertilization with tandem-configured disc units.
• Strip-till soil pre-processing and seedbed preparation.

• High working speed of up to 15km/h, high seeding amount reliability.
• Highly advanced system of electronic control of each seed.
• Electronic control of all functions of the machine during work – ISO bus system.
• Double-sided fertilization with tandem-configured disc units.
• Strip-till soil pre-processing and seedbed preparation.

Robust design

High-strength refined materials in connection with eXtra STEEL line technology guarantee long service life of our machines even in the most difficult conditions.

• High-strength materials are used on key points for long-term durability.

Hydraulic folding

Hydraulic folding into the transportation position.

Maintenance free bearings

Maintenance-free bearing of all discs providing machine operation without the need of lubrication.

Resistant bearings of fertilising units

Resistant and maintenance-free rubber bearing of fertilization units for adjustment to the terrain with overload protection.

Highly resistant seeding units

Highly resistant seeding units with flexible down pressure.

Granulated fertiliser hopper alternatives

Precise Impact seed drill + modular Falcon SW seed drill

Hopper capacity 4,000 litres

Precise Impact seed drill + Monsun MF front hopper

Hopper capacity 1,100 litres

Electronic seeding control

The drill coulters are equipped with highly advanced system of seeding control. The special sensors monitor each individual seed and precisely evaluate whether or not there are gaps or two seeds in one point. All information about the work of the seed drill is displayed on the ISO-bus terminal in the tractor. Therefore, the operator can immediately check all the functions of the machines and adapt the adjustments or speed to the current soil conditions.

¹ Recommended towing vehicle, the actual pulling force may significantly change according to the tilling depth, soil conditions, inclination of land, wear of working units and their adjustment.
² Alternative to hydraulic brake / operating pressure of 130 ± 5 bar.
³ Transport / brake system: Follow national provisions valid for transport of machines on public roads. Verify legal provisions valid in the country, regulations on maximum allowable total weights and axle loads and also on necessary possible use of the brake system. If you have any questions, please contact our sales representative.
