Planter Impact NS

Technology

1 Fertilizer placement zone. Fertilizer is placed about 5 cm next to the seed in depth of 6–12 cm. While the fertilizer is being placed, the seedbed is also partially compacted.
2 Crop residue spreading zone. The clearing stars efficiently remove crop residue from the surface for seeding.
3 Seedbed formation and seed placement zone. The double disc coulters efficiently create a compacted seedbed (V-groove) and place the seeds precisely at the required depth. Due to the high down-pressure, the seeding coulters can carry up to 70% of the machine weight. The compacted seedbed and V-groove provide excellent contact of the seed with soil and soil water.
4 Zone for pressing the seed into the V-groove and its stabilization in the precise place.
5 Side seed compression zone. The press roller presses the V-groove with the seed, due to which the seed is pressed into the soil on the side. A loose area for easy crop emergence stays above the seed.

Technics

Planter Impact NS

  1. Double-sided fertilisation with disc units.
  2. Seeding units for precise seed distribution.

Impact is designed for precise seeding of wide-row crops (maize, sunflower, and rapeseed) with the option of additional fertilization using granulated fertilizers. Impact has a massive frame. Ensuring precise placement of the fertilizer and the seeds in the required depth, also in heavier soil conditions.

The system of tandem-configured disc fertilization units not only provides precise double-sided placement of fertilizer in the root zone, but also strip-till pre-processing allowing for subsequent precise placement of seeds into the prepared seedbed.

The design of the Impact seed drill allows reaching high working speed according to the soil conditions: from 10 to 15km/h.

Impact is designed for precise seeding of wide-row crops (maize, sunflower, and rapeseed) with the option of additional fertilization using granulated fertilizers. Impact has a massive frame. Ensuring precise placement of the fertilizer and the seeds in the required depth, also in heavier soil conditions.

The system of tandem-configured disc fertilization units not only provides precise double-sided placement of fertilizer in the root zone, but also strip-till pre-processing allowing for subsequent precise placement of seeds into the prepared seedbed.

The design of the Impact seed drill allows reaching high working speed according to the soil conditions: from 10 to 15km/h.

High performance and quality of work

  • High working speed of up to 15km/h, high seeding amount reliability.
  • Highly advanced system of electronic control of each seed.
  • Electronic control of all functions of the machine during work – ISO bus system.
  • Double-sided fertilization with tandem-configured disc units.
  • Strip-till soil pre-processing and seedbed preparation.
  • High working speed of up to 15km/h, high seeding amount reliability.
  • Highly advanced system of electronic control of each seed.
  • Electronic control of all functions of the machine during work – ISO bus system.
  • Double-sided fertilization with tandem-configured disc units.
  • Strip-till soil pre-processing and seedbed preparation.

Robust design

High-strength refined materials in connection with eXtra STEEL line technology guarantee long service life of our machines even in the most difficult conditions.

  • High-strength materials are used on key points for long-term durability.
Hydraulic folding
Hydraulic folding into the transportation position.
Maintenance free bearings
Maintenance-free bearing of all discs providing machine operation without the need of lubrication.
Resistant bearings of fertilising units
Resistant and maintenance-free rubber bearing of fertilization units for adjustment to the terrain with overload protection.
Highly resistant seeding units
Highly resistant seeding units with flexible down pressure.

Granulated fertiliser hopper alternatives

Precise Impact seed drill + modular Falcon SW seed drill
Hopper capacity 4,000 litres
Precise Impact seed drill + Monsun MF front hopper
Hopper capacity 1,100 litres

Electronic seeding control

The drill coulters are equipped with highly advanced system of seeding control. The special sensors monitor each individual seed and precisely evaluate whether or not there are gaps or two seeds in one point. All information about the work of the seed drill is displayed on the ISO-bus terminal in the tractor. Therefore, the operator can immediately check all the functions of the machines and adapt the adjustments or speed to the current soil conditions.

Parameters

Technical parameters Units Impact 6 NS Impact 8 NS
Working width mm 4 500 6 000
Transport width mm 3 000 3 000
Transport height mm 2 400
Total machine length mm 2 350 2 350
Working depth mm 100  100
Hopper capacity / 1 drill coulter l 35 35
Pressure of drill coulters kg 40 40
Diameter of sowing discs mm 390 390
Working performance ha/h 4,5─6  6─9
Towing vehicle 1 kW
HP
75
100
90
125
Working speed km/h  6─15 6─15
Maximum transport speed 3 km/h 20  20
Maximum slope availability ° 6
Required pressure 2 kPa  8
Number of hydraulic circuits / pressure bar 3 / 200   3 / 200
Number of hydro-couples / type   6 / ISO 12,5  6 / ISO 12,5
Oil flow for machine control l/min 30 30
Electric system requirement  A 30 30
Tractor hitch requirement   TBZ cat. 3 TBZ cat. 3
Machine weight kg 2 700 3 200


1 Recommended towing vehicle, the actual pulling force may significantly change according to the tilling depth, soil conditions, inclination of land, wear of working units and their adjustment.
2 Alternative to hydraulic brake / operating pressure of 130 ± 5 bar.
Transport / brake system: Follow national provisions valid for transport of machines on public roads. Verify legal provisions valid in the country, regulations on maximum allowable total weights and axle loads and also on necessary possible use of the brake system. If you have any questions, please contact our sales representative.

Optional

Photo gallery

Video

Files

User manual

Accessories

Display Units

BASIC-Terminal
Equipment
Display Dimensions 5,7"
ISO-BUS OK
Seed Passing Sensor Control OK
Hopper Level Reading OK
Fan Speed Reading OK
Dispenser Speed Reading OK
Motor Speed Reading OK
Number of Motors (Dispensing) 3
Tramline Flap Control OK
Seed Drill Position Display OK
Work Lighting Control OK
Hopper Lighting Control OK
Marker Control OK
Pre-emergent Marking Control OK
Adding Seed Batch during Work OK
Micro Seeding OK
Simultaneously Running Screens 1
Camera Input x
GSM Modem x

Müller Elektronik: ISOBUS DRILL-Controller

TOUCH800®
Equipment
Display Dimensions 8"
ISO-BUS OK
Seed Passing Sensor Control OK
Hopper Level Reading OK
Fan Speed Reading OK
Dispenser Speed Reading OK
Motor Speed Reading OK
Number of Motors (Dispensing) 3
Tramline Flap Control OK
Seed Drill Position Display OK
Work Lighting Control OK
Hopper Lighting Control OK
Marker Control OK
Pre-emergent Marking Control OK
Adding Seed Batch during Work OK
Micro Seeding OK
Simultaneously Running Screens 2
Camera Input OK
GSM Modem x

Müller Elektronik: ISOBUS DRILL-Controller

SMART570®
Equipment
Display Dimensions 5,7"
ISO-BUS OK
Seed Passing Sensor Control OK
Hopper Level Reading OK
Fan Speed Reading OK
Dispenser Speed Reading OK
Motor Speed Reading OK
Number of Motors (Dispensing) 3
Tramline Flap Control OK
Seed Drill Position Display OK
Work Lighting Control OK
Hopper Lighting Control OK
Marker Control OK
Pre-emergent Marking Control OK
Adding Seed Batch during Work OK
Micro Seeding OK
Simultaneously Running Screens 1
Camera Input x
GSM Modem x

Müller Elektronik: ISOBUS DRILL-Controller

Topcon XD+
Equipment
Display Dimensions 12,1"
ISO-BUS OK
Seed Passing Sensor Control OK
Hopper Level Reading OK
Fan Speed Reading OK
Dispenser Speed Reading OK
Motor Speed Reading OK
Number of Motors (Dispensing) 3
Tramline Flap Control OK
Seed Drill Position Display OK
Work Lighting Control OK
Hopper Lighting Control OK
Marker Control OK
Pre-emergent Marking Control OK
Adding Seed Batch during Work OK
Micro Seeding OK
Simultaneously Running Screens 5
Camera Input OK
GSM Modem for a fee

Müller Elektronik: ISOBUS DRILL-Controller

x Not available
OK Included
